Description
Copper conductor, EPR Insulation, Copper Tape Screen with aluminium welded corrugated armoured and PVC Sheath
Construction :
| A. | Compact circular stranded copper conductor | ||||||||||||||||||
| B. | Extruded semiconductive compund conductor screen | ||||||||||||||||||
| C. | Extruded EPR insulation | ||||||||||||||||||
| D. | Extruded strippable semiconductive compund insul screen | ||||||||||||||||||
| E. | Helically overlapped copper tape metalic screen | ||||||||||||||||||
| F. | Copper grounding conductors | ||||||||||||||||||
| G. | Polypropylene yarn filler & polyester tape binder | ||||||||||||||||||
| H. | Aluminium welded corrugated armour | ||||||||||||||||||
| I. | Extruded PVC 90°C grade outer sheath ( orange colour ) |
Identification of Cores :
| Phase | : | Identification by PE Tape ( Black, Red, Blue ) |
| Grounding | : | Uninsulated |
| Other specification are available on request |
Symbol : MV-105 MC-HL 35kV or CU/EPR/CTS/MC/PVC
| Applicable Standard | : | Rated Voltage : 35 kV |
| Specification | : | IEC 60502-2 ICEA 60502-2 UL 1072 |
| Other Specification are available on request | ||
| Application | : | * Indoor and outdoor ( wet or dry location ) * Branch circuit for power distribution system * Installation direct burial * Installation cable tray * Approved for classes I, II and III division 1 and 2, class 1, zones 1 and 2 |
