MV-105 MC-HL 15 KV

MV-105 MC-HL 15 KV

Fiber Optic & Copper Cables

Fiber Optic Accessories

Description

Copper conductor, EPR insulation, copper tape screen with aluminium welded corrugated armoured and PVC sheath

Construction :

Compact circular stranded copper conductor
Extruded semiconductive compund conductor screen
Extruded EPR insulation
Extruded strippable semiconductive compound insul screen
Helically overlapped copper tape metalic screen
Copper grounding conductors
Polypropylene yarn filler & polyester tape binder
Aluminium welded corrugated armour
Extruded PVC 90°C grade outer sheath ( red colour )

Identification of Cores :

Phase Identification by PE tape ( black, red, blue )
Grounding Uninsulated
Other specification are available on request
Symbol MV-105 MC-HL 15 kV or CU/EPR/CTS/MC/PVC
Applicable Standard Rated Voltage : 15 kV
Specification : IEC 60502-2
ICEA S-93-639
UL 1072
Other Specification are available on request
Application * Indoor and outdoor ( wet or dry location )
* Branch circuits for power distribution system
* Installation direct burial
* Installation cable tray
* Approved for classes I, II and III division 1 and 2,class 1, zones 1 and 2

Construction

CONSTRUCTION

     Item Number No. of Core Size Conductor Grounding Conductor Thickness Insulation Diameter over Insulation Overall Diameter Core Overall Diameter Armour Sheath Thickness Approx Overall Diameter Cable Approx Net. Weight Standard Length
Construction No. of Wire
    AWG/kcmil  mm2     No x Size (AWG) mm mm mm mm mm mm Kg/Km m
DMCHL3002301015E 3 2 33,6 cm 7 3 x10 5,59 20,58 45,9 57,1 1,52 60,5 4280 1000
DMCHL3001300815E 3 1 42,4 cm 19 3 x 8 5,59 21,38 47,7 58,9 1,52 62,3 4771 1000
DMCHL3010300815E 3 1/0 53,4 cm 19 3 x 8 5,59 22,38 49,8 61,0 1,91 65,2 5389 1000
DMCHL3020300815E 3 2/0 67,4 cm 19 3 x 8 5,59 23,38 52,0 65,6 1,91 69,8 6165 1000
DMCHL3040300715E 3 4/0 107 cm 35 3 x 7 5,59 25,98 57,6 71,2 1,91 75,4 7829 500
DMCHL3250300715E 3 250 127 cm 35 3 x 7 5,59 26,98 59,8 73,4 1,91 77,6 8578 500
DMCHL3350300615E 3 350 177 cm 35 3 x 6 5,59 29,48 65,2 79,4 2,16 84,1 10689 500
DMCHL3500300515E 3 500 253 cm 35 3 x 5 5,59 32,58 71,9 87,9 2,16 92,6 13765 500
DMCHL3750300415E 3 750 380 cm 56 3 x 4 5,59 36,78 80,9 96,9 2,16 101,6 18312 350
