Description
Construction :
| 1. Conductor | : | Annealed copper wire |
| 2. Insulation | : | Extruded solid polyethylene |
| 3. Water Protective | : | Jelly Filling Compound |
| 4. Core Covering | : | Helically overlapped crape paper tape |
| 5. Screen | : | Longitudinally overlapped aluminium tape |
| 6. Outer Sheath | : | Extruded black polyethylene |
Symbol : Jelly Filled Duct Cable Tp-EJ ( Pe ) E
| Size Ranged | : | 10 … 400 x 2 x 0.8mm² 10 … 800 x 2 x 0.6mm² 10 … 1200 x 2 x 0.4mm² |
| Applicable Standard | : | STEL-K 008/SII.0618-82 Other Specification are available on request |
| Application | : | Jelly filled, water protective cable for primary or secondary circuit for laying in duct |
