Description
Construction
| 1. Conductor | : | Annealed Copper Wire |
| 2. Insulation | : | Extruded Solid Polyethylene |
| 3. Water Protective | : | Jelly Filing Compound |
| 4. Core Covering | : | Helically Overlapped Crepe Paper Tape |
| 5. Screen | : | Longitudinally Overlapped Aluminium Tape |
| 6. Inner Sheath | : | Extruded Black Polyethylene |
| 7. Armour | : | Helically Overlapped Galvanized Steel Tape ( Double Coated ) |
| 8. Outer Sheath | : | Extruded Black Polyethylene |
Symbol : Jelly Filled Armoured Cable T-EJ ( Perm ) E
| Size Ranged | : | 10 … 400 x 2 x 0.8mm² 10 … 800 x 2 x 0.6mm² 10 … 1200 x 2 x 0.4mm² |
| Applicable Standard | : | STEL-K 007/SII.0617-82 Other Specification are available on request |
| Application | : | Cable for secondary circuit direct burial/underground |
